co2 laser engraver portable fractional co2 laser with 3% dicount
heory of CO2 Fractional Laser
CO2 Fractional laser is the most advanced conceptual fractional CO2 skin peeling laser system with a wavelength of 10600nm. In addition to its fine skin-peeling effect, it can effectively penetrate the laser beam into the dermis . It is the most beneficial skin recovery system and can achieve the long-term effect of collagen remodeling as well as improvement of aged skin conditions due to exposure to light. It can be very safely applied to various types of scars compared to the existing 100% total layer skin peeling lasers (CO2 or Er: YAG). In addition, it does not require a long period of recovery or side effects. It can remodel various types of deformed scars and skin tissue very effectively.
Application of CO2 Fractional Laser
Application of Ablation laser resurfacing:
CO2 fractional laser for skin tightening , fractional skin resurfacing , Skin renewing, wrinkle removal, whitening , pore minimization ;
Acne scar removal one surgery , Smooth burnt scars and surgery scars, dermabrasion , Remove intractable chloasmas and pigmentation; etc
Application of co2 laser cutting:
in aesthetic surgery .it is mainly used for cutting on blepharoplasty , skin tags and ingrown nails , compound nevus and intra dermal nevus etc
Advantage of CO2 Fractional Laser
1.USA radio frequency laser, high quality and excellent performance, long life
2.Smaller focal spot, stronger penetration and powerful output energy
3.8 or 10 large touch- screen, smart operation system
4.Excellent treatment results, not affect people's normal life and study
Technical Specification of CO2 Fractional Laser
| Laser type | Carbon Dioxide fractional(fraxel) laser /Metal RF tube |
| Laser mode | TEMoo |
| Power | 30W |
| Max power intensity | 75, 000 W / cm² |
| Radiation time | 0.01 1 sec |
| Aiming beam | Less than 2mW, 635nm red semiconductor laser |
| Condenser focus | f=100mm |
| Pulse energy | 10mj to 100mj is optional for each dot |
| Wavelength | 10600nm |
| Laser Work mode | Ultra pulse , fractional CW |
| Output way | Fractional beam& scan beam |
| Cooling system | Wind cooling with treatment head. Water cooling with machine (glass tube ) |
| Dot number | at max 2000 dots (glass) at max 3000 dots (radio frequency ) |
| Scan mode | Random, sequence, convergence , diagonal even/odd etc |
| Scan Graphics | Square , circle , rectangular , triangle , line, customized graphics |
| Spot distance(pitch) | 0.12-1.25mm(adjustable) |
| Spot size | 0.2mm |
| Penetrate depth | 2mm |
| Pulse duration | 0.1-20ms for optional |
| overlay | 1 to 20 times |
| Transmission system(Beam delivery ) | Articulated arm with 7 mirrors |
| Display | 10.4 inch big color touch screen |
| Dimension | 52cm(L)*58cm(W)*90cm(H) |
| Weight | 38KG |
| Power supply | 220V 50HZ , 110V 60HZ |
